Design

• LED indicators: Activity, LAN, System, WLAN
• Product colour: Black
• Product type: Tabletop router

Features

• Built-in processor: Y

Other features

• Intelligent Mesh technology: Y
• Reset button: Y
• Web-based management: Y

Network

• 5G: N
• Auto MDI/MDI-X: Y
• Ethernet LAN: Y
• Ethernet LAN data rates: 10,100,1000,2500 Mbit/s
• Ethernet LAN interface type: Gigabit Ethernet
• Networking standards: IEEE 802.3,IEEE 802.3ab,IEEE 802.3u
• Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
• Wi-Fi standards: 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax)

Ports & interfaces

• DC-in jack: Y
• Ethernet LAN (RJ-45) ports: 5
• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1

Power

• Output current: 4 A
• Output voltage: 12 V
• Power source type: DC

Weight & dimensions

• Depth: 270 mm
• Height: 174 mm
• Width: 270 mm

Antenna

• Antenna type: External
• Antennas quantity: 12

Memory

• Internal memory: 1000 MB

Mobile network

• 3G: N
• 4G: N

Operational conditions

• Operating temperature (T-T): 0 – 40 °C
• Storage temperature (T-T): -40 – 70 °C

Processor

• Processor cores: 4
• Processor frequency: 2200 MHz
• Processor manufacturer: Qualcomm

Security

• Access Control List (ACL): Y
• Security algorithms: WPA-PSK,WPA2-PSK,WPA3-SAE

WAN connection

• Ethernet WAN: Y
• SIM card slot: N

Wireless LAN features

• Wi-Fi band: Tri-band (2.4 GHz / 5 GHz / 5 GHz)
• WLAN data transfer rate (first band): 2402 Mbit/s
• WLAN data transfer rate (max): 4804 Mbit/s
• WLAN data transfer rate (second band): 4804 Mbit/s
• WLAN data transfer rate (third band): 1148 Mbit/s
