Design

• Antenna design: External
• Product colour: White
• Product type: Tabletop router

Other features

• Reset button: Yes

Network

• Cabling technology: 10/100/1000Base-T(X)
• Ethernet LAN: Yes
• Ethernet LAN data rates: 10,100,1000 Mbit/s
• Ethernet LAN interface type: Gigabit Ethernet
• Networking standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
• Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
• Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)

Ports & interfaces

• DC-in jack: Yes
• Ethernet LAN (RJ-45) ports: 4
• Memory card slot(s): No
• USB port: No

Power

• Power source type: AC

Weight & dimensions

• Depth: 143.5 mm
• Height: 178.7 mm
• Width: 247 mm

Packaging data

• Antenna included: Yes
• Package type: Box

Antenna

• Antennas quantity: 4

Operational conditions

• Operating relative humidity (H-H): 5 – 90%
• Operating temperature (T-T): 0 – 40 °C
• Storage temperature (T-T): -40 – 70 °C

Packaging content

• AC adapter included: Yes
• Cables included: LAN (RJ-45)
• Manual: Yes

Security

• Security algorithms: WPA-PSK, WPA2-PSK, WPA3-SAE

Technical details

• Indication light: Yes

WAN connection

• 3G/4G USB modem compatibility: No
• Ethernet WAN: Yes
• SIM card slot: No

Wireless LAN features

• Modulation: 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, OFDM, OQPSK
• Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
• WLAN data transfer rate (max): 1201 Mbit/s
