Design

• On/off switch: Y
• Product colour: White
• Product type: Tabletop router

Features

• Built-in processor: Y

Network

• Cabling technology: 10/100Base-T(X)
• Ethernet LAN: Y
• Ethernet LAN data rates: 10,100 Mbit/s
• Ethernet LAN interface type: Fast Ethernet
• Number of guest networks (2.4 GHz): 13
• Number of guest networks (5 GHz): 165
• Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
• Wi-Fi standards: 802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac)

Ports & interfaces

• Memory card slot(s): N

Power

• Output current: 1 A
• Output voltage: 12 V
• Power source type: AC

Weight & dimensions

• Depth: 122 mm
• Height: 174 mm
• Width: 201 mm

Antenna

• Antenna gain level (max): 6 dBi
• Antenna type: Internal
• Antennas quantity: 4

Mobile network

• 3G: N
• 4G: N

Operational conditions

• Operating relative humidity (H-H): 10 – 90%
• Operating temperature (T-T): 0 – 40 °C
• Storage relative humidity (H-H): 5 – 90%
• Storage temperature (T-T): -40 – 70 °C

Processor

• Processor cores: 2

Security

• Security algorithms: WPA-PSK

System requirements

• Minimum RAM: 128 MB
• Mobile operating systems supported: Android, iOS

WAN connection

• 3G/4G USB modem compatibility: N
• DSL WAN: N
• Ethernet WAN: Y
• SIM card slot: N

Wireless LAN features

• Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
• WLAN data transfer rate (first band): 300 Mbit/s
• WLAN data transfer rate (second band): 867 Mbit/s
